Tau ntev, muaj kev xav tsis zoo hauv kev lag luam. Lub zog noj ntawm cov tshuab ziab khaub ncaws adsorption tsuas yog sib npaug nrog cov khoom siv hluav taws xob rov ua dua tshiab. Txawm hais tias qhov tsis yog - thermal regeneration hom muaj tus nqi pib qis, nws 15% mus rau 30% kev noj ntawm cov khoom siv roj zaum kawg yog qhov tseem ceeb rau cov khoom pov tseg tas li ntawm kev ua haujlwm ntawm lub tshuab cua compressor. Txawm hais tias hloov kho mus rau micro-thermal regeneration type, txawm hais tias huab cua siv tau tuaj yeem txo mus rau 5% mus rau 7%, qhov kev siv hluav taws xob ntxiv ntawm lub rhaub hluav taws xob ua rau lub zog tshiab.
Txoj kev daws teeb meem ntawm NUZHUO yog nyob rau hauv "kub rov qab" es tsis yog "gas noj". Nws compression heat regenerative adsorption drying system ncaj qha siv 100-140℃high-temperature compressed air discharged from the final stage of air compressor as the regeneration heat source. Lub ntsiab lus ntawm txoj kev no yog "hloov cov khoom pov tseg rau hauv cov khoom muaj nqis": cov cua kub compressed uas yuav tsis poob los ntawm lub txias txias yog siv los ua kom sov lub adsorbent nyob rau hauv lub regeneration ntauwd, cia cov ya raws nyob rau hauv lub adsorbent desorb nyob rau hauv lub siab. Txij li cov txheej txheem rov tsim dua tshiab tshwm sim hauv lub voj kaw, cov roj cua sov thiab txias theem yog qhov kawg tag nrho rov qab los rau hauv cov kav dej sib txuas, ua tiav kev ua haujlwm "zero gas" tiag tiag.
Txawm hais tias ib txwm siv tshuab compression tshav kub rov qab yog lub zog heev -ntau, nws feem ntau ntsib qhov kev txwv uas cov dej lwg tsis tuaj yeem tshaj -20 degree, uas txwv tsis pub nws daim ntawv thov nyob rau hauv siab -xav tau teb xws li precision manufacturing, electronics, thiab tshuaj. NUZHUO tau kov yeej qhov kev tsis sib haum xeeb no los ntawm "ob-theem cua sov regeneration" txheej txheem: Thawj theem siv cov cua compressor compression cua sov kom tshem tawm kwv yees li 80% ntawm cov dej noo los ntawm cov adsorbent; theem thib ob qhia txog lub twj tso kua mis kom tshem tawm kwv yees li 4% mus rau 10% ntawm cov roj ua tiav, uas yog tom qab ntawd rov ua kom sov los ntawm lub tshuab hluav taws xob ua ntej "sib sib zog nqus desorption" ntawm lub adsorption ntauwd.
Raws li daim ntawv thov rooj plaub ntawm NUZHUO ua haujlwm rau cov tuam txhab hlau loj, tom qab hloov cov tsoos micro cua sov rov ua dua tshiab rau hauv xoom roj siv compression cua sov qauv, los ntawm kev rov ua kom cov cua sov khib nyiab ntawm lub tshuab cua compressor, tsis yog tsuas yog poob ntawm cov khoom siv roj raug tshem tawm (sib npaug rau kev txuag lub peev xwm ntawm ntau tshaj ib lub tshuab cua compressor), tab sis kuj yog lub zog tseem ceeb ntawm cov hluav taws xob hluav taws xob {{0}. Cov ntaub ntawv sib piv qhia tau hais tias kev siv hluav taws xob ua haujlwm tag nrho ntawm xoom roj siv hluav taws xob siv hluav taws xob rov ua dua tshiab yog 15% - 30% qis dua qhov tsis yog- cov qauv tsim hluav taws xob, thiab txuag kwv yees li ob - feem peb ntawm cov nqi hluav taws xob piv rau cov qauv cua sov sab nraud.
NUZHUO cov cuab yeej tseem tau nruab nrog kev tswj xyuas ntse raws li qhov sib txawv ntawm qhov ntsuas siab thiab ntsuas qhov dej lwg. Nws tuaj yeem ua kom zoo dua lub sijhawm ntawm ntauwd lub cev hloov raws li qhov tseeb load, zam qhov "siab sib txawv hloov" qhov teeb meem uas tshwm sim vim lub sijhawm tswj tsis raug. Qhov kev lag luam no- lees paub qhov teeb meem ntev tsis tsuas yog ua rau cov adsorbent rau hmoov thiab cov li qub kom puas, tab sis kuj txo cov adsorption efficiency li ntawm 12.5%.
